CERTECH 70M HDMI Active Optical Cable, High Speed 1080P 4K@30Hz, w/ Ethernet

Stock Code:
CHDMIAOC70
Make an Enquiry
CHDMIAOC70
CERTECH 70M HDMI Active Optical Cable, High Speed 1080P 4K@30Hz, w/ Ethernet

Product Overview

CERTECH 70M HDMI Active Optical Cable, High Speed 1080P 4K@30Hz, w/ Ethernet

CERTECH's range of HDMI Active Optical Cables (AOC), allow you to display HDMI sources at UHD 4K@30Hz
Using optical fibre, these cables provide high reliability HDMI signal transmission, with no signal loss or EMI interference, providing a much higher performance than any standard copper solution.
No external power source is required, as these operate exactly like a 1m cable.

Supported Data Rate: 6.0Gbps, 10.2Gbps
HDMI Clock: 27-340MHz
TDMS: 4 x Polymer Insulated Glass Fibers
Conductors: 30 AWG Tinned copper wire
4C + HEAC Pairs: Polymer
Shielding - Overall: AL/Braid
Cable Jacket Material: LSZH Composite, 10m-100m lengths
HDMI Connector Shell: Premium gauge folded steel, 24K Gold plated
HDMI Connector Pins: Solid OFC, 24K Gold plated
Termination: Contactless IR induction soldering
Active Optical Technology: Directional, In-shell Optical Light Engine
Cable Diameter: 5.00mm 0.2mm / 0.19
Mounting Depth: 70.0mm/2.76
Cable Bend Radius: 20.0mm/0.78
Retention Force (nom): 9.8N (1kg / 2.2lbs) +10/-5%
