EDIMAX 8 Port Gigabit Ethernet PoE+ Switch, 75W
Product Overview
Long range 8 port Gigabit PoE+ switch with DIP switch
- Gigabit High Speed PoE+: Equipped with 8 Gigabit PoE+ ports, IEEE 802.3af/at PoE compliant, supports up to 30W per PoE port (total power budget: 70W)
- PoE Long Range Extension: Guaranteed PoE transmit distance to 200 metres at speed of 10Mbps
- Port-based VLAN: Port isolated from each other to prevent multicast or broadcast storms
- Hardware QoS: Easy DIP switch setup QoS, supports 802.1p, for video & voice traffic priority
- PoE Auto Detection: Auto detect PoE and non-PoE devices to avoid from being damaged by incorrect power sending
- Power Backfeed Protection: Equipped with power backfeed protection to avoid damaging the PoE ports
- Plug-and-Play, Flexible Network Deployment and Energy Efficient
- Fanless, Compact, Rack-Mount, Durable Metal Casing
PoE Long Range Extension
Supports PoE power output over a distance up to 200 meters overcoming the 100 meters limit on Ethernet UTP cable with the PoE Extend “ON”, the GS-1008PL V2 provides an additional solution for 802.3at/af PoE distance extension, thus saving the cost of Ethernet cable installation.
Innovative Port-Based VLAN
The GS-1008PL V2 features port-based VLAN where ports can be easily isolated from each other. This can help to prevent IP camera’s multicast or broadcast storms from affecting each other.
Easy Hardware QoS
Supports 802.1p QoS via DIP switch port 4. This ensures first priority for video and voice traffic for reduced package loss, lower latency and jitter on the network.
Safe Power Backed Protection
Each port equipped with power backfeed protection to avoid damaging the PoE ports while the non-standard PSE (Power Sourcing Equipments) are connected.
