EDIMAX Industrial Surveillance VLAN 48 Port Gigabit PoE+Web Smart Switch w/ 6 10GbE SFP+ Ports
Stock Code:
IGS-5654PLX
IGS-5654PLX
EDIMAX Industrial Surveillance VLAN 48 Port Gigabit PoE+Web Smart Switch w/ 6 10GbE SFP+ Ports
Product Overview
Industrial Surveillance VLAN 54-Port Gigabit PoE+ Web Smart Switch with 6 10GbE SFP+ Ports
- 48 Gigabit Ethernet PoE+ ports and 6 10GbE SFP+ ports
- Wide operating temperature range of -20° ~+65° C (-4° ~+149° F) for industrial or extreme environments
- Dual PoE power budget supplies up to 800W in classic mode and 400W in industrial mode (default)
- One-click to create Surveillance VLAN and auto-discover, auto-enrolled devices all at once
- Dedicated Intelligent Thermal Controller to control fan speeds for power saving and noise reduction
- PoE powered devices (PD) alive check to enhance the reliability of the network
- Dual-power-supply and dual-firmware-image for robust failover mechanisms
- Guaranteed PoE long distance to 200 meters
- Power backfeed protection to avoid damaging the PoE ports
- IP Surveillance VLAN and Voice VLAN to enhance video and voice quality
- DHCP snooping to protect the integrity of the legitimate DHCP server and its operations
- IEEE 802.3af/at PoE compliant, up to 30W per port (total power budget: 800W or 400W) for powering PoE-enabled devices
- Supports SNMP v1/v2c/v3, Access Control List (ACL), QoS, 802.1Q VLAN, IPv4/IPv6, Port Trunking, Port Mirroring, IGMP v1/v2/v3 Snooping and etc.
- Supports 216Gbps backplane bandwidth, 160.7Mpps forwarding rate, 32 MAC address table and 12KB jumbo frame
Strong Data Switching Capability
With 216Gbps backplane bandwidth, the switch has a strong switching capability for sending data to the destination devices at ultra-high speed.
Further Network Connection
The long-range mode provides extended power and data delivery distance to 200 meters (656 ft.) at 10Mbps full-duplex operation on a per-port basis.
Reliable Network
The switch has two firmware stores. The additional backup firmware can be activated while the main firmware goes under restoration, reducing system downtime.
